Technical Specification |
|
| Inner Tank MAterial | Zero Sprangle galvanize steel make 1.6mm thickness |
| Coating | Rust Proof - "PE Silica" 120 micron thickness coating using European Technology |
| Coating Process | Abrasive Blasting process using Copper slag on pre-coated sheets |
| Heating Process | Coated tank go through 200 deg C. Pre-Heated Oven. |
| Best Quality | Passed 3 Level Q.C with Acid Testing |
Collector |
|
| Collector Type | Evacuated Tube Collector |
| Materials | Borosilicate Glass 3.3 |
| Selective Coating | AL/SS/CU Three Layer Coating |
| Tube Length | 1800mm |
| Diameter | 58 Dia |
| Tube wall thickness | 1.8+/- 0.15mm |
| Tube Weight | 2.2kg |
Hot Water Tank Stand |
|
| Material | 32/3mm MS L Angle of 1 inch thickness and cross bars 5mm thick. |
| Coating | Anti-corrosion Epoxy Powder Coating |
| Rib | GS 1.2mm Rectangular Box for Bottom tube holder |
